FEATURES

• 4'' Pop-Up Height
• 6 1/4'' Body Height
• Dual pressure-activated seal (cap to flow tube and cap to body)
• Easy grip threaded cover
• Stainless steel “super strength” retraction spring
• High-strength ribbed design
• Directional flush cap on every head
• Large Self-cleaning Check Valve

PRS FEATURES

MAX SELF-CLEANING CHECK VALVE

• Factory installed check valve: 14 ft/hd @ 18 PSI (4.3 m/hd @ 1,2 BAR)
• Enhanced debris resistance through expanded surface area
• Tapered design for self-cleaning operation
• Positive seal even in dirty water environment

MAX PRESSURE REGULATION

• Reduces water consumption by up to 50%
• Eliminates wasted water caused by high pressure – no misting and fogging
• Optimizes outlet pressure for consistent performance, even with pressure variations

NOZZLES

• Completely compatible with all industry-standard female thread nozzles
• Adjustable Arc nozzles
• MPR Nozzles
• Rotary Nozzles

OPERATING DATA

• Pressure range: 15 to 70 psi (1,0 to 4,8 bars)
• Blow-by: Zero at 5 psi (0,3 bars) or greater
• Factory installed check valve: 14 ft/hd at 18 psi (4.3 m/hd at 1,2 bar).

MAX SPRING

Every Max Spray model includes a super-strength spring with over 37% stronger retraction force than the leading competitor. Result: Max Spray better prevents stick-ups in the field.

• Industry’s strongest spring for positive retraction
• Corrosion resistant stainless steel material for long life
• Unique reversible spring design can be installed in either direction for simple, fast field assembly
