Rain Bird - MDCFCOUP - 1/2'' MDCF Coupling - Easy Fit Compression Fitting System
Rain Bird - MDCFCOUP - 1/2'' MDCF Coupling - Easy Fit Compression Fitting System is backordered and will ship as soon as it is back in stock.
- Reduces inventory costs: Multi-diameter compression fittings work with a wide range of 16mm - 17mm tubing or dripline
- Saves time and effort: 50% less force is required to connect tubing and fittings versus competitive compression fittings. Adapters swivel for easy installation
- Provides increased flexibility: Just three Easy Fit Fittings and five Easy Fit Adapters are needed to make over 160 combinations of connections, accommodating countless installation and maintenance situations
- Works with all 16-17mm dripline and blank tubing
- Patented fittings and adapters are molded from UV-resistant and durable ABS materials
- Removable flush caps can be used to flush end of line and temporarily cap off lines for later expansion
- Not recommended with subsurface irrigation
Note: Easy Fit Adapters are not barbed fittings. They are to be used only with Easy Fit Compression Fittings.
Complete system of compression fittings and adapters for all tubing connection needs in a low-volume system.
Operating Range
- Pressure: 0 to 60 psi (0 to 4.1 bar)
- Accepts tubing with an O.D. of 0.630" to 0.669" (16-17mm)
- Recommended for use above surface only
Reduces inventory costs: Multi-diameter compression fittings work with a wide range of 1/2" polyethylene tubing sizes (0.630" to 0.669" or 16mm - 17mm outside diameter).
Saves time and effort: 50% less force is required to connect tubing and fittings versus competitive compression fittings. Adapters swivel for easy installation.
-
Box QuantityN/A
