Two valves on only one wire: Let Add-A-Zone solve your irrigation problems!
Work around broken zone wires. Add a new zone without adding new wiring. Add-A-Zone is the proven way to independently control two zone valves with only one pair of field wires.
Unlike other “switching” units, the Add-A-Zone behaves just like the valves are fully independent. A patented unit installed at the controller allows use of two separate zones, while sending the signal through only one field wire.
Features & Benefits
- Both valves connected to an Add-A-Zone are independently timed and activated from the controller for both manual and automatic operation
- The 2 valves can be assigned to separate watering schedules and programs in the controller
- Permits easy addition of an additional valve to controllers with spare stations without the need to divide out a run
time on a single zone or activate the new valve every other watering cycle - Makes adding a valve to correct water pressure problems easy
- Broken wires can be abandoned and worked around without loss of programming flexibility
- Fast and inexpensive to install
- The added valve can be a master valve
Installation Instructions
Adapter Part A (installs in controller cabinet)
- Connect Brown wire to one station output
- Connect Red wire to existing common wire
- Connect Black wire to the good field wire
Adapter Part B (bury in ground where convenient)
- Connect Black wire to existing zone wire
- Connect White wire to existing common wire
- Connect Red and White wire to the first control valve
- Connect Brown and White wire to the second control valve
Electrical Specifications
- Operates on most 24-Volt sprinkler systems
- Switching capacity: 0.5 A
- Life Expectancy: 50,000 operations
Why Choose Add-A-Zone
- Add-A-Zone behaves as if the valves are fully independent, unlike other switching devices which means there's no need for "watering every other cycle".
- Unit is installed at an open station on the controller and allows two valves to have separate watering schedules and programs while the signal is sent through one wire.
- Maximum control and flexibility that installs in minutes!
- Both solenoid valves connected through the Add-A-Zone can be independently timed and controlled for automatic and manual operations.
- Very simple and inexpensive to use.
- Eliminates the need to disrupt the landscape by digging in new wires.
